Features and Product Sheets

Product Sheets

Supported Devices

See Charging Stations for the full compatibility list.

Supported Protocols

• OCPP 1.6: Main communication protocol for chargepoints
• LMS-protocol: Support for master-satellite Ecotap communication & communication to back-office
• Supervisor protocol (deprecated)
• EVBox g2 & g3 support
• Modbus RTU and Modbus TCP: Energy meters, solar inverters, batteries, and specific chargepoints(Peblar, Kreisel Chimaro)
• Solar Spec interface: For solar inverters
• P1 DSMR: Physical interface for communication with smart energy meters

Load Balancing Options

• Balance grids by Current (default), Active Power, Apparent Power, or KW-limits
• Multiple grids per Edge support
• Nested grid hierarchies supported
• Energy meters in primary/sub-grids
• Real-time MI insights
• External API grid control
• Solar charging support
• Dynamic flexible opening hours
• Charge profiles at grid and chargepoint levels
• Export limits and solar inverter curtailment
• Battery peak shaving & self consumption integration

Device Management

• Maximum number of chargepoints per Edge: 200
• Connector capacity scales with connected chargepoints
• Automatic chargepoint reconfiguration for load balancing
• Offline capabilities with card database for authorization
• Transaction management during connectivity loss
• Back-office management features (resets, blocking, remote start/stop, status retrieval, parameter changes, diagnostics, firmware updates)
• EdgeManager accessibility

Interoperatability

• Rest API(Local and cloud)
• Modbus server API
